What is a paper cup sleeve glue equipment? What is it used for? How much is the paper sleeve making machine? Read here to learn more about the paper cup sleeve machine for sale.
YG-35 Duoble wall paper cup sleeve forming machine is the automatic equipment through the procedure of automatic feeding, sealing, gluing, and closing at one time to let the cups have a double layer or ripple layer to avoid heat. Contact us to get the Automatic Paper Cup Sleeve Machine With Ultrasonic Sealing Price.
Paper Cup Sleeve Machine Parameters
Here are the technical parameters of our paper cup sleeve machine. Note: We can customize the machine and mold according to the customer’s requirements.
| Name | PAPER CUP SLEEVE MACHINE (DOUBLE LAYER/RIPPLE LAYER) |
| Model | YG-35 |
| Paper Cup Size | 6-16oz |
| Paper Cup Top Diameter | Min 65mm-max94mm |
| Paper Cup Bottom Diameter | Min45mm-60mm |
| Paper Cup Height | Min60mm-135mm |
| Raw Material | PE-COATED PAPER. RIPPLE PAPER ETC |
| Speed | 50-55pcs/min (Speed of 20 hours stable running per day) |
| Suitable paper weight | 150-350gsm |
| Voltage supply | 220v50hz single phase/ 380v50hz 3-phase (better to use 380v50hz 3-phase) *If the user’s voltage supply is different, please inform us in advance. |
| General power | 4.7KW |
| Net weight | 1500kgs |
| Measurement (mm) | 2150*950*1650MM |
| Cup Side Sealing | Ultrasonic |
Features
- The automatic lubrication system reduces the wear of machine parts and improves the stability of equipment production.
- Reasonable design, and stable operation of equipment.
- Easy to operate.
- The machine adopts Ultrasonic sealing.
- It is a multifunctional Cup Sleeve Glue Machine. It can produce hollow cups, corrugated cups, and solid paste cups.
- The equipment is suitable for double-layer milk tea cups, double-layer coffee cups, and corrugated cups.
Paper Cup Sleeve Machine Working video
YG Paper Machinery
Henan YG Paper Machinery is a professional paper products making machine machinery. With more than 17 years of manufacturing, our equipment has been exported to many countries and been praised by our customers. We provide paper making machine, paper roll rewinder, paper cup machine, paper bowl making machine, paper plate making machine, etc. If you want to buy the machine, please contact us. Factory Price, High quality. Fast delivery. 7/24 online services support.
