A paper calender machine is a device used to improve the glossiness of paper. It is an important part of the whole paper making production line. Generally, we install the paper calender between the drying section and the reel. Do you want to change this machine for your paper mill? Or are you looking for paper calender equipment to improve the smoothness, gloss, tightness and thickness uniformity of the paper web? Read this article to learn more!
What is a Calender Machine for paper?
A Calender is a series of hard pressure rollers used to finish or smooth a sheet of material such as paper, textiles, rubber, or plastics. The paper calender machine is an important part of papermaking, The equipment is composed of three or four hard pressure rollers. The roller is made of chilled cast iron alloys. Its work surface has high hardness,wear-resistance, and durable life. The paper passes by the rollers, and it is compacted and becomes smooth. The pressure exerted by the rollers on the web determines the finish of the paper. Generally, the gloss is about 65-85%, and it can reach more than 90-95% gloss after calendering.
Contact us here to get the calendering machine for paper.
What is Paper Calendering Machine used for?
The Paper Calender Machine can:
- Improve the quality of the final product.
- Make the surface of the paper extra smooth.
- Make the thickness of the final product more uniform.
Paper Calender Machine Parameters
| Product Name | Calender |
| 3Design speed | 120m/min |
| Gauge | 1790mm |
| Roll surface width | 1300mm |
| Dimension | 6000*3200*1900mm |
| Capacity | 30-450 T |
| Max. paper Width | 1200mm |
| Finished Products Inner Diameter | 32~60 mm |
| Jumbo roll stander | 1-3 plies |
| Voltage | 380v |
Operating procedures
The working method of the calender is usually continuous rolling. The printed matter is conveyed from the paper feeding table to the calendering belt between the hot pressing roller and the pressure roller. And under the action of temperature and pressure, the coating is attached to the surface of the calendering belt and calendered. After calendering, the glazing layer gradually cools to form a bright surface layer. The calendering belt is a specially treated stainless steel endless steel belt. There are multiple groups of far-infrared heating sources installed inside the hot pressing roller to provide the heat required for calendering.
The pressure of the pressing roller mostly adopts an electro-hydraulic pressure regulating system, which can accurately meet the pressure requirements in calendering. The speed-adjustable drive motor or a slip motor can control the speed of calendering.
Our Company
In the past 17 years of production and sales, we have owned a group of excellent technical teams. We have a complete pre-sales service, after-sales technical support, and strict control of the product quality management system. Our machines sell well in 18 provinces across the country. And we export to more than 10 countries and regions such as Vietnam, Mongolia, Brazil, Uzbekistan, West Africa, and South Africa.
About Us
YG Paper Machinery is located in zhengzhou, henan province. With more than 17 years of machine manufacturing, we design and manufacture the paper making machines. Our hot sales machine: paper cup forming machine, paper pulper machine, paper cutting machine,
If you have any questions, please feel free to contact us and look forward to cooperating with you!
